Transparent OLED Displays

Parameter

Panel

Panel Brand

LG

Display Size

55-inch

Panel Technology

OLED

Contrast

(150000:1)

Native Resolution

3,840 x 2,160

Brightness

400(APL25%, Typ.,cd/m²)
150(APL100%, Typ.,cd/m²)

Viewing angle （H*V）

178*178

Surface treatment

Hard coating (2H)
Anti-reflection treatment

Life time

30000hrs

Operation Hours

18hrs/7days(moving video only)

Orientation

Lanscape&Portrait

Interface

Input

HDMI, DP, USB2.0(2)

Output

DP, Audio(Fixed/Off/Variable)

External control

RS232C IN/out,RJ45 In/out,IR In

Frame color

black

Physical characteristics

Bezel Width (T/B/L/R)

0.6 /0.6/6.7/6.7mm (Flat,Off Bezel)
5.0/5.0/7.8/13.2mm (Flat, On Bezel)

Monitor dimension(W*H*D)

701.4*1219.7*38.0mm(Head, w/Pem-nut)
701.4*1219.7*12.4mm（Head only）Signage

Weight

11.3kg set Signage
Box:3.5KG

Package Weight

18.9kg

Carton Dimension(W*H*D)

1350*837*250mm

Other Function

Temperature sensor, cooling fan, splicing mode, source selection (HDMI, DP), eye protection DPM selection, energy saving, dynamic
image eye protection technology, 128 GB memory (system 4 GB + 124 GB available)
HDMI-CEC firmware update (LAN), failover (DP, HDMI, memory), DP daisy link

Environmental conditions

Operating temperature

0°C to 40°C

Working humidity

10% to 80%

Power

Voltage

100-240V~，50/60HZ

Supply type

Built-in power

Power Consumption(Typ./Max.)

309W/318W(Based on 8 color bar)

Standard certification

CCC, FCC

Media player compatibility

OPS Type Compatible

N/A

External media player attachable

YES

Software compatibility

Content Management Software

YES

Control and monitoring Software

YES

Accessories

Basic

Remote controller, Power Cord, QSG, IR Receiver, Regulation Book,
Phone to RS232C GENDER, RS232 Cable (4p-4p),
FCC cable(220mm*4ea for Connection between Panel and Signage box)
DP cable, Lan cable, LC(VLC Cable)
