P2.0/P2.5/P3

Pixel Pitch(mm)

2.5 mm

Pixel Configuration

SMD 1921

Pixel Matrix per Panel(dots)

192 x 192 dots

Pixel Density(dots/m²)

160,000 dots/m²

Cabinet Size(mm)

480 x 480 x 63mm

Panel Dimension(W×H×D)

( 18.9”×18.9”×2.5”)

Panel Material

Die-casting Aluminum

Panel Weight(kg/panel)

5.1 kg/panel (12.3 lb/panel )

Color Depth(Bit)

14 bit

Refresh Rate(Hz)

≥2880Hz

Driver Method/scan

Scan 1/32

Brightness(nits)

1000nits, adjustable

Horizontal Viewing Angle(°)

160 °

Vertical Viewing Angle(°)

160 °

AC Power Input(V)

AC110V~ 220V ±10%

AC Power Frequency(Hz)

50 ~ 60 Hz

Max. Power(W/m²)

520 W/m²

Avg. Power(W/m²)

170 W/m²

Storage/Operating Humidity(RH )

10% ~ 90%RH

IP Rating(IP )

IP30 / IP30

Lifetime Typical Value(Hrs)

100,000 Hrs

Installation Type

Fix , Front installation

Maintenance Method

Front & Rear serviceable

Certifications

CE, Rohs, FCC, TUV-CE,ETL
